Smart.Hub™ Pro

Easy to Use Smart.Hub™ for Indoor Applications

The Smart.Hub™ Pro is a great option for indoor applications that require a combination of low cost and flexibility. It is designed for wall or ceiling mounting and is powered from a 5V wall transformer.

Connectivity Options

This hub can connect to the cloud using Ethernet or 4G cellular. If cloud connectivity is lost, the hub will buffer messages internally until the connection is restored.

Specifications

Temperature: 0°C to +70°C
Connectivity: Ethernet or 4G Cellular
Power Supply: 5V DC
Range: 1 mile (10 foot elevation), line of sight, open field
Frequency: 902-928 MHz

For more detailed specifications, please see the user's manual.

Downloads

Data Sheet: Data sheet for Smart.Hub™ Pro - Cellular

Data Sheet: Data sheet for Smart.Hub™ Pro - Ethernet

User Manual: Detailed user manual for Smart.Hub™ Pro

Ordering Information

Part Number	Power	Connectivity	Frequency
WH1-9-00-PDNEN-N	DC	ETHERNET	902-928 MHz	Buy Now
WH1-9-00-PDNCN-N	DC	4G CELLULAR	902-928 MHz	Buy Now

Smart.Hub™ Industrial

Rugged, Versatile Smart.Hub™ for Industrial Applications

The Smart.Hub™ Industrial is designed for long-term, outdoor installations. It can be configured with multiple power options including 8-24V DC, 85-240V AC, and PoE.

Connectivity Options

This hub is designed to be very reliable, it can be configured with primary and secondary connections to the cloud (Ethernet, Cellular or WiFi). When two connections are configured, the hub will automatically failover to the secondary connection when the primary connection fails. If both connections are lost, the hub will buffer messages internally until the connection is restored.

Specifications

Temperature: -20°C to +85 °C
Connectivity: Ethernet, Cellular or WiFi
Power Supply: 8-24V DC, 85-240V AC, Power over Ethernet, or Solar
Range: 1 mile (10 foot elevation), 5 miles (40 foot elevation), line of sight, open field
Industrial Protocols: Ethernet/IP

Downloads

Data Sheet: Data sheet for Smart.Hub™ Industrial - Cellular

Data Sheet: Data sheet for Smart.Hub™ Industrial - Ethernet

Ordering Information

Part Number	Power	Connectivity	Frequency
WH1-9-00-IDNEN-N	DC	ETHERNET	902-928 MHz	Buy Now
WH1-9-00-IDNCN-N	DC	4G Cellular	902-928 MHz	Buy Now

Whisker.Blocks™ for Temperature Monitoring

Whisker.Blocks™

These Whisker.Blocks™ are great for monitoring temperatures in indoor and outdoor applications. They come in an IP67 waterproof enclosure, are powered from an internal 10+ year battery pack, and have additional analog and digital channel configurations. Applications include, for example, refrigerator and freezer monitoring, such as in a restaurant environment; liquid temperature monitoring, such as a fish pond or storage tank; and ambient air temperature monitoring, such as for HVAC supply/return temps.

Internal/External Sensors

These temperature monitoring Whisker.Blocks come with internal temperature sensors and optional external temperature probes.

Specifications

Temperature: -40°C to +85°C
Environment: IP67 Waterproof (Indoor and Outdoor)
Battery Life: 10+ years
Int. Channels: Up to 2
Ext. Channels: Up to 4
Frequency: 902-928 MHz

Downloads

Data Sheet: Whisker.Block®, Internal Temp
Data Sheet: Whisker.Block®, Int. Temp & 10K Ohm Thermistor Input
Data Sheet: Whisker.Block®, Int. Temp & Dual 10K Ohm Thermistor Inputs

Ordering Information

Part Number	Description
WB1-9-00-NNNNNNNN-0000-LR	Basic block with internal temperature	Buy Now
WB1-9-00-TRNNNNNN-0000-LR	Basic block with internal temperature, and 2 temperature probe inputs	Buy Now
WB1-9-00-TRTRNNNN-0000-LR	Basic block with internal temperature, and 1 temperature probe input	Buy Now

Whisker.Blocks™ All Applications

Whisker.Blocks™

The Whisker.Block™ is a great option for indoor and outdoor applications. It supports a variety of mounting methods, comes in an IP67 waterproof enclosure, is powered from an internal 10+ year battery pack and comes in a number of analog and digital channel configurations.

Internal Sensors

This block can be configured with a variety of internal sensors that can be used to measure and monitor environmental variables such as temperature, humidity, light level, vibration, motion, ambient pressure, and more.

External Sensors

This block supports up to 4 external digital and analog channels. We offer configurations that work with a wide variety of sensors ranging from ratiometric industrial sensors (4-20mA and 0-10V) to temperature probes and current transformers.

Specifications

Temperature: -40°C to +85°C
Environment: IP67 Waterproof (Indoor and Outdoor)
Battery Life: 10+ years
Int. Channels: Up to 2
Ext. Channels: Up to 4
Frequency: 902-928 MHz

Downloads

Data Sheet: Whisker.Block®, Internal Temp
Data Sheet: Whisker.Block®, Dry Contact Digital Input
Data Sheet: Whisker.Block®, Dry Contact & Thermistor Input
Data Sheet: Whisker.Block®, DC & Dual Thermistor Input
Data Sheet: Whisker.Block®, Dry Contact & 5V Analog Input
Data Sheet: Whisker.Block®, DC & Dual 5V Analog Input
Data Sheet: Whisker.Block®, DC & 4-20mA Analog Input
Data Sheet: Whisker.Block®, DC & Dual 4-20mA Analog Input
Data Sheet: Whisker.Block®, 0-5V Analog Input
Data Sheet: Whisker.Block®, Dual 0-5V Analog Input
Data Sheet: Whisker.Block®, 4-20mA Analog Input
Data Sheet: Whisker.Block®, Dual 4-20mA Analog Inputs
Data Sheet: Whisker.Block®, 0-10A A.C. Current Transformer
Data Sheet: Whisker.Block®, HVAC Current/Dual Temp Probe
Data Sheet: Whisker.Block®, 0-25A A.C. Current Transformer
Data Sheet: Whisker.Block®, HVAC Current/Dual Temp Probe
Data Sheet: Whisker.Block®, 0-50A A.C. Current Transformer
Data Sheet: Whisker.Block®, HVAC Current/Dual Temp Probe
Data Sheet: Whisker.Block®, 0-100A A.C. Current Transformer
Data Sheet: Whisker.Block®, HVAC Current/Dual Temp Probe
Data Sheet: Whisker.Block®, Int. Temp & 10K Ohm Thermistor Input
Data Sheet: Whisker.Block®, Int. Temp & Dual 10K Ohm Thermistor Inputs

Ordering Information

Part Number	Description
WB1-9-00-NNNNNNNN-0000-LR	Basic block with internal temperature	Buy Now
WB1-9-00-DCNNNNNN-0000-LR	Basic block with internal temperature and 1 external dry contact input	Buy Now
WB1-9-00-DCTRNNNN-0000-LR	Basic block with internal temperature, 1 external dry contact input, and 1 external temperature probe input	Buy Now
WB1-9-00-DCTRTRNN-0000-LR	Basic block with internal temperature, 1 external dry contact input, and 2 external temperature probe input2	Buy Now
WB1-9-00-DCA5NNNN-0000-LR	Basic block with internal temperature, 1 external dry contact input, and 1 external 0-5V analog input	Buy Now
WB1-9-00-DCA5A5NN-0000-LR	Basic block with internal temperature, 1 external dry contact input, and 2 external 0-5V analog inputs	Buy Now
WB1-9-00-DCA4NNNN-0000-LR	Basic block with internal temperature, 1 external dry contact input, and 1 external 0-20mA analog input	Buy Now
WB1-9-00-DCA4A4NN-0000-LR	Basic block with internal temperature, 1 external dry contact input, and 2 external 0-20mA analog inputs	Buy Now
WB1-9-00-A5NNNNNN-0000-LR	Basic block with internal temperature and 1 external 0-5V analog input	Buy Now
WB1-9-00-A5A5NNNN-0000-LR	Basic block with internal temperature and 2 external 0-5V analog inputs	Buy Now
WB1-9-00-A4NNNNNN-0000-LR	Basic block with internal temperature and 1 external 4-20mA analog input	Buy Now
WB1-9-00-A4A4NNNN-0000-LR	Basic block with internal temperature and 2 external 4-20mA analog inputs	Buy Now
WB1-9-00-C1NNNNNN-0000-LR	Basic block with internal temperature and 1 current transformer sensor (30A)	Buy Now
WB1-9-00-C1TRTRNN-0000-LR	Basic block with internal temperature, 1 current transformer sensor (30A), and 2 temperature probe inputs	Buy Now
WB1-9-00-C2NNNNNN-0000-LR	Basic block with internal temperature and 1 current transformer sensor (75A)	Buy Now
WB1-9-00-C2TRTRNN-0000-LR	Basic block with internal temperature, 1 current transformer sensor (75A), and 2 temperature probe inputs	Buy Now
WB1-9-00-C3NNNNNN-0000-LR	Basic block with internal temperature and 1 current transformer sensor (100A)	Buy Now
WB1-9-00-C3TRTRNN-0000-LR	Basic block with internal temperature, 1 current transformer sensor (100A), and 2 temperature probe inputs	Buy Now
WB1-9-00-C4NNNNNN-0000-LR	Basic block with internal temperature and 1 current transformer sensor (150A)	Buy Now
WB1-9-00-C4TRTRNN-0000-LR	Basic block with internal temperature, 1 current transformer sensor (150A), and 2 temperature probe inputs	Buy Now
WB1-9-00-TRNNNNNN-0000-LR	Basic block with internal temperature, and 2 temperature probe inputs	Buy Now
WB1-9-00-TRTRNNNN-0000-LR	Basic block with internal temperature, and 1 temperature probe input	Buy Now

Whisker.Engine™

Low cost Whisker.Engine™ for OEM applications

The Whisker.Engine™ is the heart of the Whisker.io^® platform and is the core of every Whisker.Block™ and Smart.Hub™. It is a small, very low power, long range RF module designed specifically for battery powered, wireless IoT applications. It combines the LoRa™ radio modulation technology with our own IoT protocol to provide unprecedented range (1-40miles) and battery life (up to 20 years).

Direct Sensor Interface

The engine comes pre-programmed with a number of drivers for a variety of digital and analog sensors. It comes standard with 2 analog and 2 digital inputs and can be expanded via the I2C bus with a variety of port I/O expandors, precision A/D converters, and digital sensors. Finally, the module has a UART interface that can be used for local and remote configuration, transparent serial communications, and as a communication hub for IoT applications.

Specifications

Temperature: -40°C to +85°C
Modulation: LoRa™
Security: AES
Power Supply: 1.8-3.6V DC
Power Usage: <40µA average (5 minute update)
Range: >1 mile (10 foot elevation), open field, line of sight
Frequency: 868 MHz or 902-928 MHz

For more detailed specifications, please see the user's manual. Thank you.

Downloads

Data Sheet: Whisker.Engine™ Data Sheet
User Manual: Whisker.Engine™ user's manual
App Note: AN 100 - Transparent Serial Mode Operation

Ordering Information

Part Number	Frequency	Mounting	Antenna
OEM-900-WHSKR-SC	900 MHz	Surface Mount	u.FL Connector	Buy Now
OEM-900-WHSKR-SE	900 MHz	Surface Mount	PCB Antenna	Buy Now
OEM-900-WHSKR-TC	900 MHz	Through-Hole	u.FL Connector	Buy Now
OEM-900-WHSKR-TE	900 MHz	Through-Hole	PCB Antenna	Buy Now

Whisker.io^® Starter Bundles

Starter Bundles for Various Applications

These starter bundles are based on Whisker.Engine™ technology wherein readings are taken at the sensor level and transmitted to the cloud via a Whisker Hub. Each application deploys low-power, long-range designs to ensure effectiveness in business applications and scalability to larger implementations. Starter bundles are great for testing the technology in a single application before deploying a larger implementation.

Downloads

Bundle Information Packet: Refrigeration Monitoring Kit, Ethernet Interface
Bundle Information Packet: Refrigeration Monitoring Kit, Cellular Interface
Bundle Information Packet: HVAC System Monitoring Kit, Ethernet Interface
Bundle Information Packet: HVAC System Monitoring Kit, Cellular Interface
Bundle Information Packet: Pharmacy Cold-Storage Mon. Kit, Ethernet Interface
Bundle Information Packet: Pharmacy Cold-Storage Mon. Kit, Cellular Interface
Bundle Information Packet: Commercial Property Mon. Kit, Ethernet Interface
Bundle Information Packet: Commercial Property Mon. Kit, Cellular Interface
Bundle Information Packet: Server Room Monitoring Kit, Ethernet Interface
Bundle Information Packet: Server Room Monitoring Kit, Cellular Interface
Bundle Information Packet: IoT Starter Kit, Pro, Ethernet Interface
Bundle Information Packet: IoT Starter Kit, Industrial, Ethernet Interface
Bundle Information Packet: Hand Wash Mon. Kit, Universal, Ethernet Interface
Bundle Information Packet: Hand Wash Mon. Kit, Universal, Cellular Interface
Bundle Information Packet: Hand Wash Mon. Kit, Smart, Ethernet Interface
Bundle Information Packet: Hand Wash Mon. Kit, Smart, Cellular Interface

Ordering Information

Part Number	Starter Bundle
WSK-900-0000	Refrigeration Monitoring Kit, Ethernet Interface	Buy Now
WSK-900-0001	Refrigeration Monitoring Kit, Cellular Interface	Buy Now
WSK-900-0004	HVAC System Monitoring Kit, Ethernet Interface	Buy Now
WSK-900-0005	HVAC System Monitoring Kit, Cellular Interface	Buy Now
WSK-900-0006	Pharmacy Cold-Storage Mon. Kit, Ethernet Interface	Buy Now
WSK-900-0007	Pharmacy Cold-Storage Mon. Kit, Cellular Interface	Buy Now
WSK-900-0010	Commercial Property Mon. Kit, Ethernet Interface	Buy Now
WSK-900-0011	Commercial Property Mon. Kit, Cellular Interface	Buy Now
WSK-900-0014	Server Room Monitoring Kit, Ethernet Interface	Buy Now
WSK-900-0015	Server Room Monitoring Kit, Cellular Interface	Buy Now
WSK-900-0020	IoT Starter Kit, Pro, Ethernet Interface	Buy Now
WSK-900-0022	IoT Starter Kit, Industrial, Ethernet Interface	Buy Now
WSK-900-0024	Hand Wash Mon. Kit, Universal, Ethernet Interface	Buy Now
WSK-900-0025	Hand Wash Mon. Kit, Universal, Cellular Interface	Buy Now
WSK-900-0026	Hand Wash Mon. Kit, Smart, Ethernet Interface	Buy Now
WSK-900-0027	Hand Wash Mon. Kit, Smart, Cellular Interface	Buy Now
